SFT-320&340 Light Curtain for elevator spare parts safety parts

Quick Details

Type: Elevator Parts
Place of Origin: Shanghai, China (Mainland)
Brand Name: Fuji
Model Number: SFT-320&340
Detecting range: 0~3.5m
Qty of infra red diodes 320: 32diode
Beams of 320: 94~154
Qty of infra red diodes 340: 40diode
Beams of 340: 118~194
Voice Remainder: 15s after continuous detection
Protection level: IP54

Packaging & Delivery
Delivery Detail: 20 days after 100% T/T in advance

Product Description

SFT-320&340 series Light Curtain for Elevator Spare Parts safety parts



Technical Details:

Detecting range: 0~3.5m

Qty of infra red diodes 320: 32diode

Beams of320: 94~154

Qty of infra red diodes340:40diode

Beams of 340: 118~194

Voice Remainder: 15s after continuous detection

Protection level: IP54



Product characters:

Comply with home lift standards, high safety factor.

Faults tolerance function, automatically shield the faulty diodes and remind the users;

Dormancy function, prolong product`s working life;

Adopt new technology. PCBA with strong ability of corrosion resistance, and strong ability of field adaption, stable and reliable;

Beautiful appearance design, easy installation, suitable for most brand Elevators;

Advanced technics and equipments, reliable SMT surface padding techniques;

Optional for users to choose NPN&PNP output (Transistor output) without power supply box.
