Geared Elevator Traction Machine / Motor , VVVF Drive YJ200
  • Geared Elevator Traction Machine / Motor , VVVF Drive YJ200
  • Geared Elevator Traction Machine / Motor , VVVF Drive YJ200
  • Geared Elevator Traction Machine / Motor , VVVF Drive YJ200
Geared Elevator Traction Machine / Motor , VVVF Drive YJ200
Geared Elevator Traction Machine / Motor , VVVF Drive YJ200
Geared Elevator Traction Machine / Motor , VVVF Drive YJ200

Geared Elevator Traction Machine / Motor , VVVF Drive YJ200

Payment Type:
L/C,T/T
Incoterm:
FOB,CFR,CIF
Min. Order:
1 Set/Sets
Transportation:
Ocean
Contact Now
Share:
Chat Now
  • Product Description
< >
Overview
Product Attributes

Model No.: YJ200

Brand: Fuji

Type: Driving System

Load Capacity: 1000kg

Persons: 11-20

Speed: 1.00-2.00m/s

Drive Mode: AC

Control Type: Microcomputer Frequency Control

Lift Mechanism: Telescoping Lift

Use of Occasions: Indoor Type

Guide Rail: T Guide

Traction Ratio: 1:1; 2:1

Rated Capacity: 1000;1150;1600;2300kg

Supply Ability & Additional Information

Packaging: non-wooden

Productivity: 10000

Transportation: Ocean

Place of Origin: CHINA

Certificate: CE / ISO9001 / ISO14001

HS Code: 84253190

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF

Packaging & Delivery
Selling Units:
Set/Sets
Package Type:
non-wooden
Detailed Product Description
  1. YJ200 Geared Traction Machine
  2. Drive: VVVF drive
  3. Rated speed: 1.0~1.75m/s
  4. Rated capacity: 800~1000kg
  5. Static capacity:5200kg
  6. Noise level: <64dB(A)
  7. Torsional vibration: <2.0mm/s
  8. Horizontal and vertical vibrations: <0.8mm/s
  9. Mounting: mounted in machine room
  10. Arrangement: right side


Geared Traction Machine / Motor , VVVF Drive , YJ200

ID Y5700008 Y5700009 Y5700010 Y5700011 Y5700013 Y5700014
Type of Machine YJ200-VII YJ200-IX YJ200-X YJ200-XI YJ200- XII YJ200-XIII
Type of Control VVVF VVVF VVVF VVVF VVVF VVVF
Rated Load (kg) 1000 1000 1000 1000 800 800
Rated Speed (m/s) 1 1.5 1.6 1.75 1.6 1.75
Lifting Height (m) 50 80 80 80 80 80
Static Load (kg) 5200 5200 5200 5200 5200 5200
Traction Ratio 1:01 1:01 1:01 1:01 1:01 1:01
Reduction Ratio 0.084028 0.084028 0.1375 0.125694 0.175694 0.125694
Specification of Traction Sheave Φ 580-5-13 Φ 580-6-13 Φ 580-6-13 Φ 580-6-13 Φ 580-5-13 Φ 620-5-13
Groove Spacing (mm) 19 19 19 19 19 19
Type of Motor YPTD160M3 YPTD160L2 YPTD160L3 YPTD160L3 YPTD160L1 YPTD160L2
-6D4 -6D4 -6D4 -6D4 -6D4 -6D4
Power(kw) 9 13 15 15 11 13
Motor Speed (r/min) 1000 1000 1000 1000 1000 1000
Power Source (V/Hz) 380/50 380/50 380/50 380/50 380/50 380/50
Current (A) 31.2 36.3 42.7 36.3 44.7 36.3
Brake Voltage (V) DC110 DC110 DC110 DC110 DC110 DC110
